2Mb CMOS SRAM, 256K x 8 configuration, offering 45ns access time. This asynchronous, volatile memory features a parallel interface and operates from a 2.2V to 3.6V supply. Packaged in a lead-free TSOP-II, it supports industrial temperature ranges from -40°C to 85°C and is RoHS compliant.
PackageTSOP
Current18mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Cypress CY62138FV30LL-45ZSXIT technical specifications.
General
Access Time
45ns
Access Time-Max
45ns
Address Bus Width
18b
Package/Case
TSOP
Density
2Mb
Interface
Parallel
Lead Free
Lead Free
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
3.6V
Memory Size
2Mb
Memory Type
SDR, , Volatile, SRAM
Min Supply Voltage
2.2V
Mount
Surface Mount
Number of Ports
1
Number of Words
256000
Package Quantity
1000
Packaging
Tape and Reel
Radiation Hardening
No
RoHS Compliant
Yes
Series
MoBL®
Supply Current
18mA
Supply Voltage-Nom
3V
Sync/Async
Asynchronous
Temperature Grade
INDUSTRIAL
Word Size
8b
Compliance
RoHS
Compliant
