18Mb Synchronous SRAM with 3.4ns access time, operating at 167MHz. This CMOS component features a 512K x 36 configuration, a 19-bit address bus, and four ports. Packaged in a PBGA119 (FBGA-119) surface-mount format, it operates from a 3.135V to 3.6V supply voltage with a nominal 3.3V. Designed for commercial temperature ranges (0°C to 70°C), this volatile memory offers a 36-bit word size.
Frequency167MHz
PackageBGA
Current275mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Cypress CY7C1380F-167BGC technical specifications.
General
| Access Time | 3.4ns |
| Access Time-Max | 3.4ns |
| Address Bus Width | 19b |
| Package/Case | BGA |
| Density | 18Mb |
| Frequency | 167MHz |
| Lead Free | Contains Lead |
| Max Frequency | 167MHz |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 18Mb |
| Memory Type | Volatile, , SRAM |
| Min Supply Voltage | 3.135V |
| Mount | Surface Mount |
| Number of Ports | 4 |
| Number of Words | 512000 |
| Operating Supply Voltage | 3.3V |
| Package Quantity | 84 |
| Packaging | Tray |
| RoHS Compliant | No |
| Supply Current | 275mA |
| Supply Voltage-Nom | 3.3V |
| Sync/Async | Synchronous |
| Temperature Grade | COMMERCIAL |
| Word Size | 36b |
Compliance
| RoHS | Not Compliant |
Datasheet
Cypress CY7C1380F-167BGC Datasheet
Download the complete datasheet for Cypress CY7C1380F-167BGC to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
