Cypress
CY7C1426KV18-250BZXC
QDR SRAM, 4MX9, 0.45ns, CMOS, PBGA165, 13 X 15 MM, 1.40 MM HEIGHT, LEAD FREE, MO-216, FBGA-165
Frequency250MHz
PackageFBGA
Current460mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Cypress CY7C1426KV18-250BZXC technical specifications.
General
Access Time
0.45ns
Address Bus Width
20b
Package/Case
FBGA
Density
36Mb
Frequency
250MHz
Interface
Parallel
Max Frequency
250MHz
Max Operating Temperature
70°C
Max Supply Voltage
1.9V
Memory Size
36Mb
Memory Type
QDR, , RAM
Min Operating Temperature
0°C
Min Supply Voltage
1.7V
Mount
Surface Mount
Number of Ports
2
Operating Supply Voltage
1.8V
Package Quantity
136
Packaging
Tray
Radiation Hardening
No
RoHS Compliant
Yes
Supply Current
460mA
Sync/Async
Synchronous
Word Size
9b
Compliance
RoHS
Compliant
Datasheet
Cypress CY7C1426KV18-250BZXC Datasheet
Download the complete datasheet for Cypress CY7C1426KV18-250BZXC to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
