The PWS4602 is a linear benchtop power supply with an output voltage of 60V and current of 2.5A. It operates within a temperature range of 0°C to 40°C and is powered by a 220V supply voltage. The output is delivered through a screw terminal connector. The power supply is designed for use in test and measurement applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Danaher PWS4602 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Accuracy | 0.05% |
| Current - Output 1 | 2.5A |
| Interface | USB |
| Max Operating Temperature | 40°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 2.5A |
| Max Output Voltage | 60V |
| Min Output Voltage | 0V |
| Max Supply Voltage (AC) | 264V |
| Min Supply Voltage (AC) | 99V |
| Number of Outputs | 1 |
| Operating Supply Voltage | 220V |
| Output Connector | Screw Terminal |
| Output Current | 2.5A |
| Output Voltage | 60V |
| Reach SVHC Compliant | Unknown |
| Voltage - Output 1 | 60V |
| Weight | 16.094lb |
| Wire/Cable Type | Power Cord |
| RoHS | Compliant |
Download the complete datasheet for Danaher PWS4602 to view detailed technical specifications.
