Schottky rectifier diode with 1A average rectified current and 100V repetitive reverse voltage. Features a 1A forward current, 30A peak non-repetitive surge current, and 80pF capacitance. Surface mountable in an SMA package, operating from -65°C to 150°C. RoHS compliant and lead-free.
PackageSMA
Voltage100V
Current1A
Capacitance80pF
Quick Jump:
Technical Specifications
Diodes B1100-13-F technical specifications.
General
Average Rectified Current
1A
Capacitance
80pF
Package/Case
SMA
Current
1A
Current Rating
1A
Forward Current
1A
Height
2.1mm
Lead Free
Lead Free
Length
4.6mm
Max Forward Surge Current (Ifsm)
30A
Max Operating Temperature
150°C
Min Operating Temperature
-65°C
Max Repetitive Reverse Voltage (Vrrm)
100V
Max Reverse Current
500uA
Max Reverse Voltage (DC)
100V
Mount
Surface Mount
Output Current
1A
Package Quantity
5000
Packaging
Tape and Reel
Peak Non-Repetitive Surge Current
30A
Polarity
Standard
Radiation Hardening
No
Reach SVHC Compliant
No
Reverse Voltage
70V
RoHS Compliant
Yes
Termination
SMD/SMT
Voltage
100V
DC Rated Voltage
100V
Weight
0.002258oz
Width
2.92mm
Compliance
RoHS
Compliant
Datasheet
Diodes B1100-13-F Datasheet
Download the complete datasheet for Diodes B1100-13-F to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
