Diodes
DF02S-T
Bridge Rectifier Diode, 1 Phase, 1A, 200V V(RRM), Silicon, ROHS COMPLIANT, PLASTIC, DF-S, 4 PIN
PackageSMD/SMT
MountingSurface Mount
Quick Jump:
Technical Specifications
Diodes DF02S-T technical specifications.
General
Average Rectified Current
1A
Package/Case
SMD/SMT
Forward Current
1A
Height
3.4mm
Lead Free
Lead Free
Length
8.51mm
Max Operating Temperature
150°C
Min Operating Temperature
-65°C
Max Repetitive Reverse Voltage (Vrrm)
200V
Max Reverse Current
10uA
Max Surge Current
50A
Mount
Surface Mount
Number of Elements
1
Package Quantity
1500
Packaging
Tape and Reel
Peak Non-Repetitive Surge Current
50A
Radiation Hardening
No
Reverse Voltage (DC)
140V
RoHS Compliant
Yes
Termination
SMD/SMT
Width
6.5mm
Compliance
RoHS
Compliant
Datasheet
Diodes DF02S-T Datasheet
Download the complete datasheet for Diodes DF02S-T to view detailed technical specifications.
