Diodes
DSS5540X-13
Small Signal Bipolar Transistor, 4A I(C), 40V V(BR)CEO, 1-Element, PNP, Silicon, GREEN, PLASTIC PACKAGE-3
PackageSOT-89
MountingSurface Mount
PolarityPNP
Quick Jump:
Technical Specifications
Diodes DSS5540X-13 technical specifications.
General
Package/Case
SOT-89
Collector Base Voltage (VCBO)
-40V
Collector Emitter Breakdown Voltage
40V
Collector-emitter Voltage-Max
375mV
Continuous Collector Current
-4A
Emitter Base Voltage (VEBO)
-6V
Gain Bandwidth Product
60MHz
Max Breakdown Voltage
40V
Max Collector Current
4A
Max Operating Temperature
-55°C
Min Operating Temperature
150°C
Max Power Dissipation
900mW
Mount
Surface Mount
Package Quantity
2500
Packaging
Tape and Reel
Polarity
PNP
Radiation Hardening
No
Reach SVHC Compliant
Yes
RoHS Compliant
Yes
Transition Frequency
60MHz
Compliance
RoHS
Compliant
Datasheet
Diodes DSS5540X-13 Datasheet
Download the complete datasheet for Diodes DSS5540X-13 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
