The GBPC25005W is a general purpose rectifier diode with a maximum reverse voltage of 35V and a maximum surge current of 300A. It has a maximum operating temperature of 150°C and a minimum operating temperature of -65°C. The diode is available in a through hole package and is RoHS compliant. It is suitable for use in a variety of applications, including power supplies and rectification circuits.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Diodes GBPC25005W datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Diodes GBPC25005W technical specifications.
| Height | 8mm |
| Length | 28.8mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -65°C |
| Max Reverse Current | 5uA |
| Max Surge Current | 300A |
| Mount | Through Hole |
| Package Quantity | 100 |
| Packaging | Tray |
| Reverse Voltage (DC) | 35V |
| RoHS Compliant | Yes |
| Termination | Through Hole |
| Weight | 0.607065oz |
| Width | 28.8mm |
| RoHS | Compliant |
Download the complete datasheet for Diodes GBPC25005W to view detailed technical specifications.
