Surface mount power inductor featuring a shielded drum core construction with a ferrite core material. Offers 47µH inductance with a 20% tolerance, rated for 2.95A RMS current and a maximum DC current of 5.28A. Boasts a low DC resistance of 71.9mΩ and a self-resonant frequency of 100kHz. Operates within a temperature range of -40°C to 125°C and is supplied in tape and reel packaging.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Eaton DR127-470-R datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Nonstandard |
| Core Material | Ferrite |
| Current Rating | 2.95A |
| DC Resistance (DCR) | 71.9mR |
| Depth | 12.5mm |
| Height | 8mm |
| Height - Seated (Max) | 0.315inch |
| Inductance | 47uH |
| Inductance Tolerance | 20% |
| Inductor Type | POWER INDUCTOR |
| Lead Free | Lead Free |
| Length | 12.5mm |
| Max DC Current | 5.28A |
| Max Operating Temperature | 125°C |
| Military Standard | Not |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Package Quantity | 350 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Rated Current-Max | 2.95A |
| Reach SVHC Compliant | No |
| RMS Current (Irms) | 2.95A |
| RoHS Compliant | Yes |
| Saturation Current | 5.28A |
| Self Resonant Frequency | 100kHz |
| Series | DR |
| Series Resistance | 71.9mR |
| Shielding | Shielded |
| Termination | SMD/SMT |
| Test Frequency | 100kHz |
| Tolerance | 20% |
| Weight | 0.208oz |
| Width | 0.492inch |
| RoHS | Compliant |
