Technical Specifications
Eaton EASY400-POW technical specifications.
General
Current - Output 1
1.25A
Depth
56.5mm
Height
90mm
Length
71.5mm
Max Input Voltage (AC)
264V
Min Input Voltage (AC)
85V
Max Input Voltage
264V
Min Input Voltage
85V
Max Operating Temperature
55°C
Min Operating Temperature
-25°C
Max Output Current
1.25A
Max Output Power
30W
Max Output Voltage
24V
Min Output Voltage
24V
Mount
Panel
Nominal Output Voltage
24V
Number of Outputs
1
Output Current
1.25A
Output Voltage
24V
Reach SVHC Compliant
No
Series
Easy400
Voltage - Output 1
24V
Width
90mm
Compliance
RoHS
Compliant
Datasheet
Eaton EASY400-POW Datasheet
Download the complete datasheet for Eaton EASY400-POW to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
