The Eaton FAZ-D8/2 is a 2-pole circuit breaker with a current rating of 8A and a voltage rating of 415V. It is designed for DIN rail mounting and features a screw termination. The breaker is compliant with RoHS regulations but does not meet SVHC requirements. It has a depth of 72.6mm, length of 36mm, and width of 84.7mm. The Eaton FAZ-D8/2 is approved by UL and is suitable for use in applications where a 415V circuit breaker is required.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Eaton FAZ-D8/2 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Eaton FAZ-D8/2 technical specifications.
| Approvals | UL |
| Current Rating | 8A |
| Depth | 72.6mm |
| Length | 36mm |
| Mount | DIN Rail |
| Number of Poles | 2 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | FAZ |
| Termination | Screw |
| Voltage Rating | 415V |
| Voltage Rating (AC) | 277V |
| DC Rated Voltage | 125V |
| Width | 84.7mm |
| RoHS | Compliant |
