The Eaton M22-R4K7 is a linear voltage regulator LDO with a resistance of 4.7kR and a tolerance of 10%. It is designed for panel mount applications and features an IP66 rating for environmental protection. The device operates within a temperature range of -25°C to 70°C. It is not SVHC compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Eaton M22-R4K7 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Eaton M22-R4K7 technical specifications.
| Height | 29.2mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Mount | Panel |
| Output | MONO |
| Ratings | IP66 |
| Reach SVHC Compliant | No |
| Resistance | 4.7kR |
| Taper | Linear |
| Tolerance | 10% |
| Type | Potentiometer |
| RoHS | Compliant |
