The Eaton SC-10 PTC resettable fuse is a 10A, 170V device with a maximum voltage rating of 600V AC. It has a diameter of 0.41inch and a length of 1.31inch, with a termination type of clip. The fuse is packaged in bulk and is available in quantities of 10. It is RoHS compliant and has approvals from UL, CSA, and CE. The Eaton SC-10 is suitable for use in overcurrent protection applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Eaton SC-10 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, CE |
| Blow Characteristic | TIME DELAY |
| Current Rating | 10A |
| Diameter | 0.41inch |
| Fuse Current | 10A |
| Fuse Size | 1.31 X 0.41in |
| Length | 1.31inch |
| Max Voltage Rating (AC) | 600V |
| Max Voltage Rating (DC) | 170V |
| Mount | Holder |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | SC |
| Termination | Clip |
| Voltage Rating (AC) | 600V |
| DC Rated Voltage | 170V |
| Weight | 0.24oz |
| RoHS | Compliant |
