PackageNonstandard
Current Rating5.7A
MountingSurface Mount
Inductance4.7uH
Quick Jump:
Technical Specifications
Eaton UP2-4R7-R technical specifications.
General
Package/Case
Nonstandard
Current Rating
5.7A
DC Current
5.7A
DC Resistance (DCR)
17.3mR
Depth
8.76mm
Height
0.231inch
Height - Seated (Max)
0.231inch
Inductance
4.7uH
Lead Free
Lead Free
Length
0.541inch
Max DC Current
4.2A
Military Standard
Not
Mount
Surface Mount
Package Quantity
600
Packaging
Tape and Reel
Saturation Current
4.2A
Series
UNI-PAC™ 2
Shielding
Unshielded
Termination
SMD/SMT
Test Frequency
100kHz
Tolerance
20%
Weight
0.08oz
Width
0.345inch
Compliance
RoHS
Compliant
Datasheet
Eaton UP2-4R7-R Datasheet
Download the complete datasheet for Eaton UP2-4R7-R to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
