ECS-147.4-20-3X-TR

Name: ECS-147.4-20-3X-TR ECS
Brand: ECS
SKU: ECS-147.4-20-3X-TR

CRYSTAL 14.7456MHZ 20PF SMD

Frequency14.7456MHz

MountingSurface Mount

Quick Jump:

ECS ECS-147.4-20-3X-TR technical specifications.

ESR (Equivalent Series Resistance)	60R
Frequency	14.7456MHz
Frequency Stability	50ppm
Frequency Tolerance	30ppm
Height	2.3mm
Length	7.6mm
Load Capacitance	20pF
Max Operating Temperature	70°C
Min Operating Temperature	-10°C
Mount	Surface Mount
Package Quantity	3000
Packaging	Tape and Reel
RoHS Compliant	Yes
Series	CSM-3X
Termination	SMD/SMT
Tolerance	30ppm
Width	4.1mm

RoHS

Compliant

This datasheet cannot be embedded due to technical restrictions.
