Single-deck, 11-position rotary switch featuring a straight orientation and solder termination. This coded and mechanical rotary switch offers a 30° index angle with adjustable index stops and a 2.25A current rating. It is constructed with brass contacts plated in silver and a ceramic insulation material, designed for panel mounting. Mechanical life is rated at 25,000 cycles, with a maximum AC voltage rating of 115V and a DC voltage rating of 28V.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Electroswitch D7C0111N datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Length | 47.63mm |
| Contact Material | Brass |
| Contact Plating | Silver |
| Contact Style | Non-Shorting |
| Current Rating | 2.25A |
| Depth | 0.707inch |
| Index Angle | 30° |
| Index Stops | Adjustable |
| Insulation Material | Ceramic |
| Lead Free | Lead Free |
| Max Voltage Rating (AC) | 115V |
| Max Voltage Rating (DC) | 28V |
| Mechanical Life | 25000Cycles |
| Mount | Panel |
| Number of Decks | 1 |
| Number of Poles | 1 |
| Number of Poles per Deck | 1 |
| Number of Positions | 11 |
| Orientation | Straight |
| Package Quantity | 1 |
| Reach SVHC Compliant | Unknown |
| Series | D7 |
| Termination | Solder |
| Throw Configuration | SP11T |
| Voltage Rating | 28V |
| Voltage Rating (AC) | 115V |
| DC Rated Voltage | 28V |
| RoHS | Compliant |
