The Emerson DS850DC-3-003 is a 850W AC/DC power supply with a single 12V output capable of delivering 70A of current. It operates within a temperature range of 0°C to 50°C and has a maximum power dissipation of 850W. The power supply is designed for rack-mount applications and is available in a package quantity of 16 units.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Emerson DS850DC-3-003 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Emerson DS850DC-3-003 technical specifications.
| Current - Output 1 | 70A |
| Efficiency | 80% |
| Height | 1.57inch |
| Length | 11inch |
| Max Input Voltage | -75V |
| Min Input Voltage | -40V |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 850W |
| Mount | Rack |
| Number of Outputs | 1 |
| Output Power | 850W |
| Package Quantity | 16 |
| Series | DS850DC-3 (850W) |
| Voltage - Output 1 | 12V |
| Width | 3.2inch |
| RoHS | Compliant |
