The PTH12060LAZ is a 1.8V output DC/DC converter with a maximum output current of 10A and efficiency of 88%. It features under-voltage lockout (UVLO) and short-circuit protection (SCP). The converter is packaged in a surface-mount package and is available in a tray of 48 units. It has a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. The PTH12060LAZ is not RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Emerson PTH12060LAZ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SMD/SMT |
| Current - Output 1 | 10A |
| Efficiency | 88% |
| Features | UVLO, SCP |
| Height | 0.35inch |
| Length | 25.27mm |
| Max Input Voltage | 13.2V |
| Min Input Voltage | 10.8V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 10A |
| Max Power Dissipation | 18W |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Output Power | 55W |
| Package Quantity | 48 |
| Packaging | Tray |
| RoHS Compliant | No |
| Series | PTH12060 |
| Voltage - Output 1 | 1.8V |
| Width | 15.75mm |
| RoHS | Not Compliant |
