30W DIN Rail Power Supply featuring dual +/-12V outputs, each capable of delivering 1.2A. This general-purpose power supply operates across a wide input voltage range of 85V to 264V AC and supports mounting via DIN rail or panel. With a maximum operating temperature of 65°C and a minimum of -25°C, it is UL and CE approved. The unit measures 120mm in height, 65mm in width, and 33mm in length, with a weight of 0.75lb.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Emerson SCP30D12-DN datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Emerson SCP30D12-DN technical specifications.
| Approvals | UL, CE |
| Current - Output 1 | 1.2A |
| Current - Output 2 | 1.2A |
| Current Rating | 1.2A |
| Height | 120mm |
| Length | 33mm |
| Min Input Voltage (AC) | 85V |
| Max Input Voltage | 264V |
| Min Input Voltage | 85V |
| Max Operating Temperature | 65°C |
| Min Operating Temperature | -25°C |
| Max Output Current | 1.2A |
| Max Output Power | 30W |
| Mount | Panel, DIN Rail |
| Nominal Output Voltage | 12V |
| Number of Outputs | 2 |
| Output Current | 1.2A |
| Output Power | 30W |
| Output Voltage | 12V |
| Packaging | Bulk |
| Reach SVHC Compliant | Unknown |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Weight | 0.75lb |
| Width | 65mm |
| RoHS | Compliant |
