PackageTSOP
Current180mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Everspin MR4A16BYS35R technical specifications.
General
Access Time
35ns
Access Time-Max
35ns
Package/Case
TSOP
Data Bus Width
16b
Density
16Mb
Interface
Parallel
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
3.6V
Memory Size
16Mb
Memory Type
Non-Volatile, , RAM
Min Supply Voltage
3V
Mount
Surface Mount
Operating Supply Voltage
3.3V
Organization
1MX16
Package Quantity
1000
Packaging
Tape and Reel
RoHS Compliant
Yes
Supply Current
180mA
Word Size
16b
Compliance
RoHS
Compliant
Datasheet
Everspin MR4A16BYS35R Datasheet
Download the complete datasheet for Everspin MR4A16BYS35R to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
