Dual-channel USB 2.0 Hi-Speed interface controller, supporting 480Mbps data rates. Features include I²C and UART interfaces, with 2 channels and 4 transceivers. Operates from a 1.62V to 3.63V supply range, with a typical 3.3V operating voltage. This surface mount component is housed in a 64-pin LQFP package (10.1mm x 10.1mm x 1.4mm) and offers ESD protection. RoHS compliant and lead-free, it operates between -40°C and 85°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Ftdi FT2232HL-TRAY datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Ftdi FT2232HL-TRAY technical specifications.
| Package/Case | LQFP |
| Data Rate | 480Mbps |
| Dual Supply Voltage | 3.3V |
| ESD Protection | Yes |
| Features | I²C |
| Height | 1.4mm |
| Interface | UART |
| Length | 10.1mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 3.63V |
| Min Supply Voltage | 1.62V |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Transceivers | 4 |
| Operating Supply Current | 70mA |
| Operating Supply Voltage | 3.3V |
| Package Quantity | 160 |
| Packaging | Tray |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | USBmadeEZ-FIFO, FT-X, X-Chip |
| Width | 10.1mm |
| RoHS | Compliant |
