This standard round toggle switch features a 3PDT throw configuration, a current rating of 5A, and a maximum operating voltage of 28V. It is designed for sealed mount applications and is rated for use in environments with IP67 protection against dust and water. The switch has a maximum operating temperature range of -30°C to 85°C and is compliant with RoHS regulations. The actuator is made of brass and chrome, with a copper alloy contact and gold and silver plating.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 34BW3P32B4M1QT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Grayhill 34BW3P32B4M1QT technical specifications.
| Actuator Length | 7.6mm |
| Actuator Material | Brass, Chrome |
| Actuator Type | Standard Round |
| Contact Material | Copper Alloy |
| Contact Plating | Gold, Silver |
| Current Rating | 5A |
| Electrical Life | 50000Cycles |
| Illumination Type | Non-Illuminated |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -30°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 28V |
| Mount | Sealed |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ratings | IP67, Waterproof, Dust Tight |
| RoHS Compliant | Yes |
| Series | 34B |
| Switch Function | On-Off-On |
| Termination | Solder |
| Throw Configuration | 3PDT |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 28V |
| RoHS | Compliant |
