The 37F2-AB2-AC1 is a panel mount piezo switch with a maximum operating temperature range of -40°C to 85°C. It has a non-illuminated design and is rated for an operating force of 5N. The switch is packaged in a bulk format and is not radiation hardened. It features a metal package with a depth of 73mm and a length of 93mm, and is designed for front panel mounting.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 37F2-AB2-AC1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Grayhill 37F2-AB2-AC1 technical specifications.
| Package/Case | Metal |
| Depth | 73mm |
| Height | 9mm |
| Illumination Type | Non-Illuminated |
| Length | 93mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Panel, Front |
| Operating Force | 5N |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ratings | IP68, Waterproof, Dust Tight |
| Series | 37F |
| Switch Type | PIEZO |
| Termination | Cable |
| RoHS | Not CompliantNo |
