The 50KST45-01-1-02N is a 45° index rotary switch with 2 positions and a SPDT throw configuration. It has a maximum voltage rating of 28V DC and is designed for panel mount applications. The switch features a metal contact material with gold plating and is RoHS compliant. It is rated for 220V AC and has a fixed index stop. The switch is available from Grayhill.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 50KST45-01-1-02N datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Length | 9.53mm |
| Contact Material | Metal |
| Contact Plating | Gold |
| Index Angle | 45° |
| Index Stops | Fixed |
| Max Voltage Rating (AC) | 220V |
| Max Voltage Rating (DC) | 28V |
| Mount | Panel |
| Number of Decks | 1 |
| Number of Poles per Deck | 1 |
| Number of Positions | 2 |
| RoHS Compliant | Yes |
| Series | 50 |
| Termination | Solder |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 115V |
| DC Rated Voltage | 28V |
| RoHS | Compliant |
