This optical encoder is a panel mount device with a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. It has a maximum supply voltage of 3.3V and is rated for 1,000,000 cycles of mechanical life. The encoder is IP67 rated, making it waterproof and dust tight. It has a top view orientation and outputs data via an I2C interface.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 67A-DF-3C-030C datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Grayhill 67A-DF-3C-030C technical specifications.
| Actuator Type | KNOB TYPE |
| Built in Switch | No |
| Detent | No |
| Encoder Type | Optical |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.3V |
| Mechanical Life | 1000000Cycles |
| Min Operating Temperature | -40°C |
| Mount | Panel |
| Operating Force | 300gf |
| Orientation | Top View |
| Output Type | I2C |
| Package Quantity | 1 |
| Ratings | IP67, Waterproof, Dust Tight |
| Reach SVHC Compliant | No |
| Series | 67A |
| Termination | Cable |
| RoHS | Compliant |
