General purpose I/O relay module featuring a 240VAC nominal input voltage and 3.5A output current. This module offers 4000Vrms isolation and a 1-pole, SPST throw configuration. Designed for through-hole mounting, it operates across a wide temperature range of -40°C to 100°C. Approvals include UL, CSA, CE, and TUV, with a lead-free construction.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 70G-OAC24A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Grayhill 70G-OAC24A technical specifications.
| Approvals | UL, CSA, CE, TUV |
| Package/Case | Module |
| Color | Black |
| Current Rating | 3.5A |
| Depth | 11.7mm |
| Height | 55.9mm |
| Input Current | 8mA |
| Input Resistance | 2.7kR |
| Input Type | AC |
| Lead Free | Lead Free |
| Length | 48.3mm |
| Max Input Voltage | 32V |
| Min Input Voltage | 18V |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole, Screw, PCB |
| Nominal Input Voltage (AC) | 240V |
| Number of Poles | 1 |
| Output Current | 3.5A |
| Output Type | Digital |
| Reach SVHC Compliant | No |
| Series | 70 |
| Termination | PC Pins |
| Throw Configuration | SPST |
| Turn-Off Delay Time | 8.33ms |
| Turn-On Delay Time | 8.33ms |
| DC Rated Voltage | 240V |
| RoHS | Not Compliant |
