MountingThrough Hole, Panel
Quick Jump:
Technical Specifications
Grayhill 71AF36-02-1-08S technical specifications.
General
Actuator Length
9.53mm
Contact Material
Silver
Index Angle
36°
Index Stops
Fixed
Max Voltage Rating (AC)
115V
Max Voltage Rating (DC)
30V
Mount
Through Hole, Panel
Number of Decks
2
Number of Poles per Deck
1
Number of Positions
8
RoHS Compliant
Yes
Series
71
Termination
PC Pin
Throw Configuration
SP8T
Voltage Rating (AC)
115V
DC Rated Voltage
30V
Compliance
RoHS
Compliant
Datasheet
Grayhill 71AF36-02-1-08S Datasheet
Download the complete datasheet for Grayhill 71AF36-02-1-08S to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
