This slide switch is a single-position, right-angle actuator with a copper alloy contact and gold-nickel plating. It has a maximum operating temperature of 85°C and a mechanical life of 10000 cycles. The switch is rated for a maximum current of 150mA and a maximum voltage of 30V DC. It is designed for through-hole mounting and is packaged in a rail or tube. The switch is not washable and has a throw configuration of 4PST.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 78H01RAT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | Slide (Standard) |
| Body Material | Plastic |
| Contact Material | Copper Alloy |
| Contact Plating | Gold, Nickel |
| Electrical Life | 10000Cycles |
| Max Current Rating | 150mA |
| Max Operating Temperature | 85°C |
| Mechanical Life | 2000Cycles |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (DC) | 30V |
| Mount | Through Hole |
| Number of Positions | 1 |
| Orientation | Right Angle |
| Packaging | Rail/Tube |
| Series | 78 |
| Termination | PC Pins |
| Throw Configuration | 4PST |
| DC Rated Voltage | 30V |
| Washable | No |
| RoHS | Not Compliant |
