SPST tactile switch featuring a non-illuminated, orange nylon actuator with a standard round button design. This surface-mount component utilizes gull wing terminations and offers a 0.05A at 12V DC rating. With a mechanical life of 300,000 cycles, it operates at 3.14N force and has a switch travel of 0.25mm. The switch is RoHS compliant and operates within a temperature range of -25°C to 70°C.
MountingSurface Mount
Quick Jump:
Technical Specifications
Grayhill 95C06D5GWT technical specifications.
General
Actuator Color
Orange
Actuator Material
Nylon, Polyamide
Actuator Type
Standard
Contact Material
Stainless Steel
Contact Plating
Silver
Depth
9mm
Illumination Type
Non-Illuminated
Length
6.2mm
Max Current Rating
50mA
Max Operating Temperature
70°C
Min Operating Temperature
-25°C
Max Voltage Rating (DC)
12V
Mechanical Life
300000Cycles
Mount
Surface Mount
Operating Force
3.14N
Orientation
Straight
Packaging
Rail/Tube
RoHS Compliant
Yes
Series
95C
Switch Function
Off-Mom
Switch Travel
0.25mm
Termination
Gull Wing
Throw Configuration
SPST
DC Rated Voltage
12V
Compliance
RoHS
Compliant
Datasheet
Grayhill 95C06D5GWT Datasheet
Download the complete datasheet for Grayhill 95C06D5GWT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
