SPST tactile switch featuring a non-illuminated, round brown rubber actuator with a standard type. This surface mount component utilizes gull wing terminations and offers a 0.05A at 12VDC rating. With a 1.77N operating force and 0.45mm travel, it boasts a mechanical life of 500,000 cycles and operates within a -25°C to 70°C temperature range. Bronze contacts with silver plating ensure reliable performance.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 95CW06E2GWRT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Color | Brown |
| Actuator Material | Rubber |
| Actuator Type | Standard |
| Contact Material | Bronze |
| Contact Plating | Silver |
| Depth | 5.8mm |
| Illumination Type | Non-Illuminated |
| Length | 10.29mm |
| Max Current Rating | 50mA |
| Max Operating Temperature | 70°C |
| Mechanical Life | 500000Cycles |
| Min Operating Temperature | -25°C |
| Max Voltage Rating (DC) | 12V |
| Mount | Surface Mount |
| Operating Force | 1.77N |
| Orientation | Straight |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Series | 95C |
| Switch Function | Off-Mom |
| Switch Travel | 0.45mm |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| DC Rated Voltage | 12V |
| RoHS | Compliant |
