This black PVC cable grommet has a diameter of 6.5mm and is rated for operating temperatures between -30°C and 60°C. It is made from PVC material and has a flammability rating of UL94 V-2. The grommet is designed for cable mounting and is not halogen free.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Hellermanntyton 633-05020 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Hellermanntyton 633-05020 technical specifications.
| Color | Black |
| Flammability Rating | UL94 V-2 |
| Halogen Free | Not Halogen Free |
| Height | 8mm |
| Material | PVC |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -30°C |
| Mount | Cable |
| Wire/Cable Diameter | 6.5mm |
| RoHS | Compliant |
Download the complete datasheet for Hellermanntyton 633-05020 to view detailed technical specifications.
