The Honeywell 12CX200 is a momentary action rotary switch with a current rating of 20A and a voltage rating of 120V AC. It features a chassis mount design and is rated for operation in temperatures between -25°C and 85°C. The switch is also compliant with UL and CSA approvals and has a water-resistant and dust-tight rating of IP66.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell 12CX200 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Type | Rotary |
| Approvals | UL, CSA |
| Contact Type | Momentary Action |
| Current Rating | 20A |
| Depth | 126.3mm |
| Length | 101.6mm |
| Max Current Rating | 20A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Mount | Chassis Mount |
| Number of Poles | 2 |
| Number of Positions | 2 |
| Operating Force | 0.5N |
| Ratings | IP66, Water Resistant, Dust Tight |
| Reach SVHC Compliant | No |
| Series | CX |
| Switch Function | On-Mom |
| Termination | Screw |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 120V |
| DC Rated Voltage | 125V |
| Width | 101.6mm |
| RoHS | Compliant |
