SPDT snap-action limit switch with a top plunger actuator. Features 20A contact current rating and 125V AC / 250V DC voltage rating. Chassis mount with screw terminals and conduit termination. Operating force is 112N, with pretravel of 239mm and overtravel of 556mm. RoHS compliant and UL/CSA approved, operating between -32°C and 71°C.
Current Rating20A
MountingChassis Mount, Screw
Quick Jump:
Technical Specifications
Honeywell BAF1-2RN-LH technical specifications.
General
Actuator Type
PLUNGER
Approvals
UL, CSA
Contact Current Rating
20A
Contact Type
Snap Action
Current Rating
20A
Depth
33mm
Length
101.6mm
Max Current Rating
10A
Max Operating Temperature
71°C
Min Operating Temperature
-32°C
Max Voltage Rating (DC)
250V
Mount
Chassis Mount, Screw
Number of Poles
1
Number of Positions
2
Operating Force
112N
Operating Position
5319mm
Orientation
Straight
Overtravel
556mm
Packaging
Bulk
Pretravel
239mm
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
BAF1
Switch Function
On-Mom
Termination
Conduit
Throw Configuration
SPDT
Voltage Rating (AC)
125V
DC Rated Voltage
125V
Width
54.8mm
Compliance
RoHS
Compliant
