The E7 Series Chassis Mount Snap Action Switch from Honeywell is a basic and snap action switch suitable for a variety of applications. It features a snap action contact type and can operate in temperatures up to 71 degrees Celsius. The switch has a maximum current rating of 500 milliamps and a voltage rating of 125 volts AC. It is rated for use in harsh environments, with an IP65 and IP66 rating for water resistance and dust tightness. The switch is also compliant with RoHS regulations and is available in bulk packaging. It measures 77.2 millimeters in depth, 25.4 millimeters in length, and 44.4 millimeters in width.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell BZE7-2RN2-PG datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Honeywell BZE7-2RN2-PG technical specifications.
| Contact Type | Snap Action |
| Current Rating | 15A |
| Depth | 77.2mm |
| Length | 25.4mm |
| Max Current Rating | 500mA |
| Max Operating Temperature | 71°C |
| Min Operating Temperature | -30°C |
| Mount | Chassis Mount, Screw |
| Operating Force | 556N |
| Orientation | Straight |
| Overtravel | 556mm |
| Packaging | Bulk |
| Pretravel | 478mm |
| Ratings | IP65, Water Resistant, Dust Tight, IP66 |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | E7 |
| Switch Function | On-Mom |
| Termination | Screw |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 125V |
| Width | 44.4mm |
| RoHS | Compliant |
