The CSNA111 is a Hall Effect current sensor with an accuracy of 0.5% and a current rating of 70A. It operates at a frequency of 150kHz and has a linearity of 1%. The sensor is designed for PCB mount and has a response time of 1us. It is RoHS compliant and has a maximum operating temperature of 70°C. The CSNA111 is available in a bulk packaging with 30 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell CSNA111 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Honeywell CSNA111 technical specifications.
| Accuracy | 0.5% |
| Coil Resistance | 90R |
| Current Rating | 70A |
| Current Sensing | 70A |
| Frequency | 150kHz |
| Length | 40.5mm |
| Linearity | 1% |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Supply Current | 10mA |
| Max Supply Voltage (DC) | 15.75V |
| Min Supply Voltage (DC) | 14.25V |
| Mount | PCB |
| Nominal Supply Current | 10mA |
| Number of Channels | 1 |
| Operating Frequency | 150(Max) kHz |
| Operating Supply Voltage | 15V |
| Package Quantity | 30 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Response Time | 1us |
| RoHS Compliant | Yes |
| Series | CSN |
| RoHS | Compliant |
