SPDT snap-action switch featuring a side rotary actuator and momentary operation. Rated for 10A at 250VDC and 600VAC, with a 120VAC and 125VDC rating also specified. This chassis-mount switch offers screw termination and a mechanical life of 10,000,000 cycles. Operating temperature range is -40°C to 85°C, with IP67 and IP66 ratings for waterproof and dust-tight protection. RoHS compliant.
Package300
Current Rating10A
MountingChassis Mount, Screw
Quick Jump:
Technical Specifications
Honeywell GLCB01A4J technical specifications.
General
Actuator Type
Rotary
Approvals
UL, CSA, CE, CCC
Package/Case
300
Contact Type
Snap Action
Current Rating
10A
Depth
41mm
Height
192.5mm
Length
30.5mm
Max Operating Temperature
85°C
Mechanical Life
10000000Cycles
Min Operating Temperature
-40°C
Max Voltage Rating (AC)
600V
Max Voltage Rating (DC)
250V
Mount
Chassis Mount, Screw
Operating Force
0.12N
Orientation
Right Angle
Packaging
Bulk
Ratings
IP67, Waterproof, Dust Tight, IP66
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
GLS
Switch Function
On-Mom
Termination
Screw
Throw Configuration
SPDT
Voltage Rating (AC)
120V
DC Rated Voltage
125V
Width
30.5mm
Compliance
RoHS
Compliant
Datasheet
Honeywell GLCB01A4J Datasheet
Download the complete datasheet for Honeywell GLCB01A4J to view detailed technical specifications.
