The GLCC01D is a limit switch from Honeywell with a current rating of 10A and a voltage rating of 300V AC or 250V DC. It features a screw mount and an operating force of 110N. The switch has a differential travel of 13mm and an overtravel of 52mm. It is rated for operation between -40°C and 85°C and is compliant with IP66 and RoHS regulations.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell GLCC01D datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Current Rating | 10A |
| Differential Travel | 13mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Screw |
| Operating Force | 110N |
| Operating Position | 358mm |
| Overtravel | 52mm |
| Pretravel | 345mm |
| Ratings | IP66 |
| RoHS Compliant | Yes |
| Termination | Quick Connect |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 300V |
| DC Rated Voltage | 250V |
| RoHS | Compliant |
Download the complete datasheet for Honeywell GLCC01D to view detailed technical specifications.
