The Honeywell HAFUHT0300L4AXT flow sensor operates within a temperature range of -20°C to 70°C and consumes 200mW of power. It features a threaded port and is housed in a polymer thermoplastic material. The sensor is packaged in a 300-series package and has a maximum supply voltage of 10V. It has a response time of 1ms and is part of the Zephyr HAF series.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell HAFUHT0300L4AXT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Honeywell HAFUHT0300L4AXT technical specifications.
| Body Material | Polymer, Thermoplastic |
| Package/Case | 300 |
| Material | Polymer, Thermoplastic |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -20°C |
| Max Pressure | 60PSI |
| Max Supply Voltage (DC) | 10V |
| Min Supply Voltage (DC) | 3V |
| Operating Supply Voltage | 10V |
| Packaging | Box |
| Port Style | Threaded |
| Power Consumption | 200mW |
| Reach SVHC Compliant | Unknown |
| Response Time | 1ms |
| Series | Zephyr™ HAF |
| RoHS | Compliant |
Download the complete datasheet for Honeywell HAFUHT0300L4AXT to view detailed technical specifications.
