This strain gauge pressure sensor offers a 0.25% accuracy and operates within a -40°C to 125°C temperature range. It features a 0.50-4.50V analog voltage output, a 150PSI operating pressure, and a maximum pressure rating of 450PSI. Designed with a threaded port style and stud mount, this cylindrical sensor utilizes a 5VDC supply voltage and draws 4mA operating current. It is RoHS compliant and has a 2ms response time.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell MLH150PGB06A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Honeywell MLH150PGB06A technical specifications.
| Accuracy | 0.25% |
| Lead Free | Lead Free |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Pressure | 450PSI |
| Max Supply Current | 8mA |
| Max Supply Voltage | 6V |
| Mount | Stud |
| Operating Pressure | 150PSI |
| Operating Supply Current | 4mA |
| Operating Supply Voltage | 5V |
| Output Type | Analog Voltage |
| Output Voltage | 4V |
| Packaging | Bulk |
| Port Style | Threaded |
| Pressure Type | Vented Gauge |
| Primary Type | PRESSURE SENSOR |
| Reach SVHC Compliant | No |
| Response Time | 2ms |
| RoHS Compliant | Yes |
| Series | MLH |
| Supply Current | 4mA |
| Voltage Rating | 5V |
| DC Rated Voltage | 5V |
| Weight | 57g |
| RoHS | Compliant |
