The SR16C-J5 Hall Effect Sensor from Honeywell features a ferrite actuator material and a digital output type. It operates within a temperature range of -20°C to 85°C and has a nominal supply current of 10mA. The sensor has a leakage current of 10uA and can supply an output current of 20mA at an operating supply voltage of 30V. It is mounted via a screw termination and is part of the SR16 series.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell SR16C-J5 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Material | Ferrite |
| Leakage Current | 10uA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -20°C |
| Mount | Screw |
| Nominal Supply Current | 10mA |
| Operating Supply Voltage | 30V |
| Output Current | 20mA |
| Output Type | Digital |
| Series | SR16 |
| Termination | Connector |
| Type | Hall Effect Sensor |
| RoHS | Compliant |
