Linear Hall Effect Sensor IC, SOT-89 package, operating from 3.8V to 30V supply voltage. Features a 20mA maximum output current and a 10mA nominal supply current. This surface mount device offers a wide operating temperature range of -40°C to 150°C. RoHS compliant with a 1.37mm height.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell SS549AT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOT-89 |
| Height | 1.37mm |
| Leakage Current | 10uA |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 20mA |
| Max Supply Current | 10mA |
| Max Supply Voltage (DC) | 30V |
| Min Supply Voltage (DC) | 3.8V |
| Max Supply Voltage | 30V |
| Min Supply Voltage | 3.8V |
| Mount | Surface Mount |
| Nominal Supply Current | 10mA |
| Number of Contacts | 1 |
| Operating Supply Current | 8.7mA |
| Operating Supply Voltage | 12V |
| Output Current | 20mA |
| Output Voltage | 30V |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Sensing Method | Hall Effect |
| Series | SS5 |
| Type | Integrated Circuit (IC) |
| RoHS | Compliant |
