SPDT side-adjustable rod limit switch with rotary actuator, featuring a 5A current rating at 250V AC / 125V DC. This general-purpose switch offers a mechanical life of 10,000,000 cycles and operates within a temperature range of -20°C to 60°C. Mounting options include chassis, screw, surface, and panel, with a right-angle orientation and cable termination. Rated IP64 for water and dust resistance, this RoHS compliant component is designed for reliable electromechanical applications.
Current Rating5A
MountingChassis Mount, Screw, Surface Mount, Panel
Quick Jump:
Technical Specifications
Honeywell SZL-VL-C technical specifications.
General
Actuator Type
Rotary
Approvals
UL, CE
Current Rating
5A
Depth
44.9mm
Height
204.5mm
Length
28mm
Max Current Rating
5A
Max Operating Temperature
60°C
Mechanical Life
10000000Cycles
Min Operating Temperature
-20°C
Mount
Chassis Mount, Screw, Surface Mount, Panel
Number of Poles
1
Number of Positions
2
Operating Force
784N
Orientation
Right Angle
Package Quantity
1
Packaging
Bulk
Ratings
IP64, Water Resistant, Dust Tight
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
VL
Switch Function
On-Mom
Termination
Cable
Throw Configuration
SPDT
Type
General Purpose
Voltage Rating (AC)
250V
DC Rated Voltage
125V
Width
28mm
Compliance
RoHS
Compliant
Datasheet
Honeywell SZL-VL-C Datasheet
Download the complete datasheet for Honeywell SZL-VL-C to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
