SPDT snap-action switch featuring a simulated roller lever actuator with a 328mm steel lever. Offers N.O./N.C. functionality with gold-plated gold and silver contacts, rated for 100mA at 125VAC and 10VDC. This chassis-mount switch utilizes quick connect terminations and boasts an electrical life of 100,000 cycles and a mechanical life of 10,000,000 cycles. Operating temperature range is -40°C to 82°C, with a 0.05-inch operating position.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Honeywell V7-1S17D8-263 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Honeywell V7-1S17D8-263 technical specifications.
| Actuator Length | 328mm |
| Actuator Material | Steel |
| Actuator Type | ROLLER LEVER |
| Package/Case | 125 |
| Contact Material | Gold, Silver |
| Contact Plating | Gold |
| Current Rating | 100mA |
| Depth | 10.16mm |
| Electrical Life | 100000Cycles |
| Height | 29.18mm |
| Lead Free | Lead Free |
| Length | 45.85mm |
| Max Current Rating | 100mA |
| Max Operating Temperature | 82°C |
| Max Voltage Rating (AC) | 125V |
| Max Voltage Rating (DC) | 10V |
| Mechanical Life | 10000000Cycles |
| Min Operating Temperature | -40°C |
| Mount | Chassis Mount, Screw |
| Operating Position | 0.05inch |
| Orientation | Straight |
| Overtravel | 191mm |
| Packaging | Bulk |
| Pretravel | 279mm |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Sealable | No (Without) |
| Series | V7 |
| Switch Function | On-Mom |
| Termination | Quick Connect |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| Weight | 8g |
| RoHS | Compliant |
