Frequency833MHz
Current Rating10A
MountingPanel, DIN Rail
Power240W
Quick Jump:
Technical Specifications
Idec PS5R-G24 technical specifications.
General
Current - Output 1
10A
Current Rating
10A
Frequency
833MHz
Height
4.72inch
Length
140mm
Min Input Voltage (AC)
85V
Max Input Voltage
240V
Min Input Voltage
85V
Max Operating Temperature
60°C
Min Operating Temperature
-10°C
Max Output Current
10A
Max Output Power
240W
Mount
Panel, DIN Rail
Nominal Output Voltage
24V
Number of Outputs
1
Output Current
10A
Output Power
240W
Reach SVHC Compliant
No
Voltage - Output 1
24V
Voltage Rating (AC)
240V
DC Rated Voltage
340V
Width
7.87inch
Compliance
RoHS
Compliant
Datasheet
Idec PS5R-G24 Datasheet
Download the complete datasheet for Idec PS5R-G24 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
