The IPB011N04NG is a 40V, 180A MOSFET from Infineon featuring a TO-263-7 package. It operates over a temperature range of -55°C to 175°C and has a maximum power dissipation of 250W. The device is RoHS compliant and halogen free, making it suitable for a variety of applications. The MOSFET's turn-on and turn-off delay times are 40ns and 63ns, respectively, with a fall time of 13ns.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon IPB011N04NG datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Infineon IPB011N04NG technical specifications.
| Package/Case | TO-263-7 |
| Continuous Drain Current (ID) | 180A |
| Drain to Source Voltage (Vdss) | 40V |
| Fall Time | 13ns |
| Gate to Source Voltage (Vgs) | 20V |
| Halogen Free | Halogen Free |
| Input Capacitance | 20nF |
| Max Operating Temperature | 175°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 250W |
| Package Quantity | 1000 |
| Packaging | Tape and Reel |
| Rds On Max | 1.1mR |
| RoHS Compliant | Yes |
| Series | OptiMOS™ |
| Turn-Off Delay Time | 63ns |
| Turn-On Delay Time | 40ns |
| RoHS | Compliant |
Download the complete datasheet for Infineon IPB011N04NG to view detailed technical specifications.
