The TLE4473GV55-2 is a dual 5V fixed regulator with a maximum output current of 190mA. It operates over a temperature range of -40°C to 150°C and is compliant with AEC-Q100. The device is packaged in a SOIC package and is available on tape and reel. The TLE4473GV55-2 has a quiescent current of 250uA and a dropout voltage of 200mV.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon TLE4473GV55-2 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Infineon TLE4473GV55-2 technical specifications.
| Accuracy | 2.5% |
| Package/Case | SOIC |
| Dropout Voltage | 200mV |
| Halogen Free | Halogen Free |
| Min Current Limit | 200mA |
| Max Input Voltage | 42V |
| Min Input Voltage | 5.6V |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 190mA |
| Number of Outputs | 2 |
| Number of Regulators | 2 |
| Output Current | 190mA |
| Output Type | Fixed |
| Output Voltage | 5V |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Polarity | Positive |
| Quiescent Current | 250uA |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | Automotive, AEC-Q100 |
| RoHS | Compliant |
Download the complete datasheet for Infineon TLE4473GV55-2 to view detailed technical specifications.
