The TVS3V3L4UE6327 is a lead-free zener diode from Infineon. It has a minimum breakdown voltage of 3.3V and a maximum operating temperature of 125°C. The diode is designed for surface mount applications and has a peak pulse current of 20A. It is Reach SVHC compliant and available in a cut tape packaging with a quantity of one per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon TVS3V3L4UE6327 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Diode Type | ZENER |
| Lead Free | Lead Free |
| Min Breakdown Voltage | 3.3V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 2 |
| Number of Unidirectional Channels | 4 |
| Package Quantity | 1 |
| Packaging | Cut Tape |
| Peak Pulse Current | 20A |
| Power Line Protection | No |
| Reach SVHC Compliant | Yes |
| Reverse Standoff Voltage | 3.3V |
| RoHS | Compliant |
Download the complete datasheet for Infineon TVS3V3L4UE6327 to view detailed technical specifications.
