The HA1-4741-2 is a general purpose operational amplifier with a common mode rejection ratio of 80dB and a slew rate of 1.6V/µs. It operates over a temperature range of -55°C to 125°C and is available in a CDIP package with a through hole mount. The amplifier has a nominal supply current of 4.5mA and an operating supply current of 5mA. It can handle a maximum output current of 15mA per channel and has a voltage gain of 100dB.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Intersil HA1-4741-2 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Intersil HA1-4741-2 technical specifications.
| -3db Bandwidth | 3.5MHz |
| Amplifier Type | GENERAL PURPOSE |
| Package/Case | CDIP |
| Common Mode Rejection Ratio | 80dB |
| Input Bias Current | 60nA |
| Input Offset Voltage (Vos) | 500uV |
| Lead Free | Contains Lead |
| Max Dual Supply Voltage | 20V |
| Min Dual Supply Voltage | 2V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Nominal Supply Current | 4.5mA |
| Number of Circuits | 4 |
| Operating Supply Current | 5mA |
| Output Current per Channel | 15mA |
| Package Quantity | 25 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| RoHS Compliant | No |
| Slew Rate | 1.6V/µs |
| Voltage Gain | 100dB |
| RoHS | Not CompliantNo |
