Technical Specifications
IQD LFXTAL003240 technical specifications.
General
Frequency
16MHz
Frequency Stability
50ppm
Frequency Tolerance
30ppm
Height
4mm
Lead Free
Lead Free
Length
11.05mm
Load Capacitance
30pF
Max Operating Temperature
70°C
Min Operating Temperature
-20°C
Mount
Through Hole
Reach SVHC Compliant
No
Series
HC49/4H
Series Resistance
40R
Size
4mm
Width
4.7mm
Compliance
RoHS
Compliant
Datasheet
IQD LFXTAL003240 Datasheet
Download the complete datasheet for IQD LFXTAL003240 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
