DPDT slide switch featuring a straight, extended top red actuator with a 9.55mm length. This panel mount switch offers a 6A contact current rating at 250VAC and 28VDC, with silver-plated copper contacts. Designed for 10,000 electrical cycles, it operates within a -30°C to 65°C temperature range and is UL94 V-2 flammability rated. Termination is via solder lug, with panel mounting achieved through snap-in functionality.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the ITT LP22C31T203DQ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
ITT LP22C31T203DQ technical specifications.
| Actuator Color | Red |
| Actuator Length | 9.55mm |
| Actuator Material | Glass, Acetal |
| Package/Case | 125 |
| Contact Current Rating | 6A |
| Contact Material | Copper |
| Contact Plating | Silver |
| Current Rating | 6A |
| Depth | 17.55mm |
| Electrical Life | 10000Cycles |
| Flammability Rating | UL94 V-2 |
| Lead Free | Lead Free |
| Length | 27.48mm |
| Max Current Rating | 6A |
| Max Operating Temperature | 65°C |
| Min Operating Temperature | -30°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 28V |
| Mount | Panel, Snap in, Solder |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Tray |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | LP |
| Switch Function | On-On |
| Termination | Solder |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 125V |
| RoHS | Compliant |
